Booster Pump Combo 5 – Large Home & Garden

P-LEO-EVPM6H-4|SIRIO-220V-1PH BOOST COMBO 5
R12 682.40
In stock
1
Product Details
Brand: EVP6H-4|SIRIO 220V|1PH Pressure Combo

PRESSURE BOOSTER COMBO 5 – Large Home & Garden Irrigation

Low-maintenance and easy operation

Making use of a LEO EVP vertical multi-stage pump and VSD (Variable Speed Drive) controller to ensure adequate water flow at specific pressure levels. The EVP pump combo is fully adjustable from low to medium speeds and capable of pressure ranges from 2 to 5 bar pressure at a flow of up to 150 l/min and is ideal for large homes and garden irrigation applications.

PUMP:

  • Type – Vertical Multi-Stage
  • Cast Iron water inlet and outlet – anti-rust treated
  • Support – anti-rust treated
  • Impeller – Special Plastic Material
  • AISI 304 stainless steel shaft
  • Max. suction – 8m


MOTOR:

  • Make – LEO
  • Model – EVPm6H-4
  • Power rating – 1.5kW (1500 Watt) 220 Volt
  • Phase – Single
  • C&U bearing
  • Motor with copper winding
  • Built-in thermal protector (Single Phase)
  • Insulation class – F
  • Protection class IPX4
  • Max. ambient temp – 40 *C

VSD CONTROLLER:

  • Serio – (Electronic)
  • Variable Speed Control
  • Max Pressure Point – 8 bar
  • Max Pressure Limit – 10 bar
  • Dry running protection
  • Over current protection
  • Connection thread – G1″1/4 (32mm)
  • Protection class – IP65
  • Rated motor power: 0.37 – 1.8kW


SPECIFICATION SHEET:

Download a printable flow diagram and specifications sheet – Click Here


WARRANTY:

LEO pump and controller come with a 2 year manufacturing warranty. (Terms & Conditions Apply)


OPTIONAL: (Can be selected on checkout)


WATER FILTRATION: (TRI-UC-02)

Under Counter Replaceable Cartridge Filtration with Sediment Filter – High Quality

Tripple TRI-UC-02 – under counter water filters can be neatly installed under the kitchen counter and attached to the pressurised cold water supply. Every unit comes with a Chrome Faucet that can be fitted next to your sink or prep-bowl, water connection fittings (1/2″ Easy Feed & Ball Valve), Pressure Reducer, Tubing and Wrench.

The Tripple UC-02 is a double housing under counter water filter system that utilizes a Replaceable 1 Micron sediment and a CTO carbon block with Nano-Silver filter cartridges.

The TRI-UC-02 filter system is suitable for medium sized families.


BENEFITS:

Easy to install and hidden under counter – DIY installation

Limited space required

Filter cartridge replacement: Lasts 12 – 36 months (Depending on water quality)
Low maintenance

Simple to maintain

Cost effective
Prevents bacteria growth (Bacterio-static)

Removes contaminants

Eliminates odours

Improves taste


FEATURES:

Recommended flow 1.9-3.8L/min

Maximum Expected Capacity: 18 000lt
Average Longevity: 12 – 36 months
Replaceable cartridges

Sediment pre-filter included

Multi-Stage filtration & purification

Laboratory tested

24 month manufacturing warranty (Casing and unit – excluding Filters)
Height 30.5cm
Width 27.9cm
Shipping weight: 4.5kg

SUITABLE FOR:

Rain Water & Rain Water Harvesting

Variable water supply & Boreholes

Municipal water

Rural towns with varying quality water


NOT SUITABLE FOR:

Non-municipal water
TDS levels exceeding 330mg/liter
Removal of salty taste or lime


WARRANTY:

All Tripple UC-02 Combo Water Filtration Systems come with a 2 year manufacturing warranty. (Not applicable on filters or due to poor installation) (Terms & Conditions Apply)
