DAB Hybrid Solar Pump (DC & AC) 320m Head

R30 510.00
In stock
Product Details
Brand: DAB Hybrid Solar Pumps

DAB Hybrid Solar Pump (Up to 320m Head)

DAB solar motor powers the new DAB hybrid system for the supply of clean water by utilising solar energy and if needed a generator or grid power source inputs for continuous operation. Delivery of the DAB system is done by a series of solar panels and taking advantage of the combination of the DAB S4 submersible pump range. The intelligence combined with a built-in inverter controller, the system is able to ensure a continuous drawing of water from a suitable source while the solar irradiation conditions may vary. (Automated functionality)
The DAB hybrid controller will manage additional energy inputs such as grid supplied AC power, generator AC power and activate the starting of the generator when required.

To extend the flexibility of the system, each package is supplied with,

– DAB 4” Solar Motor AC/DC 2.2kW

– DAB SOLAR Controller

– DAB S4 Multistage 4” Water Pump to suit Head and Flow requirements if applicable (Optional)

– Matched Solar panels (optional)
– Solar Panel mounting system (optional)

– Flow Sensor & Sensor Cable (optional)

– Level Probes & Submersible Cable (optional)


  • Made of AISI 304L stainless steel (Equivalent to 316)
  • Multi Stage Impeller design – 4″
  • Minimal pump vibration and noise
  • Long service lifetime


  • Made of AISI 304L stainless steel (Equivalent to 316)
  • Double outer and inner shielded structure (Submersible depth 150m) – 4″
  • Internal coil made from high-temperature tolerant copper wire
  • Efficiently protecting the motor at high-temperatures – Extends motor’s lifetime
  • Water filling lubricated rotor with top / bottom graphite bearing and thrust bearing
  • Co-axial-rotation efficiently reduces motor’s vibration and noise and extend its service lifetime.
  • Built-in, integrated Variable Frequency Converter with intelligent-speed control algorithm with speed up to 3000 RPM


The controller is a micro controller, designed, developed and manufactured for the DAB Hybrid Solar pump system.
It is suitable for simultaneous AC and DC incoming power supplies.
Manually or automatically switchable between two power supplies depending on solar irradiation.
  • IP65 weatherproof enclosure.
  • Suitable for up to 2.2 kW (3 hp) pumps.
  • AC voltage input range 90 – 280 VAC. Terminals L N & GRD
  • DC voltage input range 55 – 440 VDC. Terminals + – & GRD
  • Input connections for 1 or 2 float switches. TWL & WWL
  • Input connection for pressure switch. WWL
  • Input connection for matching flow meter. FLOW SIGNAL
  • Indication for power on, input power, pump on, pump off, water tank full or tank empty.
  • Auto operation via 1 or 2 float switches.
  • Auto operation via pressure switch.
  • Auto off via flow meter.
  • Auto starting of generator via volt free contacts. GEN SIGNAL
  • Manual operation.
  • Auto switching from AC to DC supply with DC bias. DC switching point is 90V.
** The controller will manage additional energy inputs such as grid supplied AC power, generator AC power and activate the starting of the generator when required.


  • Dry-running protection
  • Over-current protection
  • Over-voltage protection
  • Overload protection
  • Phase loss protection


Supply voltage Flexibility with regards to power supply and power range, the motor can be supplied with either DC or AC voltage:
  • AC voltage range: 90 – 280 VAC,50-60Hz
  • DC voltage range: 55 – 440VDC
  • Open circuit voltage: 90 – 440VOC
  • Output power range: 0.37 – 3.0Kw for DC
  • Output power range: 0.37 – 2.2Kw for AC


  • Watering of livestock
  • Irrigation and greenhouses
  • Game parks and game farms
  • Conservation areas
  • Surface water pumping
  • Floating pump installations for pumping water from ponds and lakes (Can be installed Horizontally)


2 Years Manufacturers warranty (Terms & Conditions as per Installation Guide)


Click here to download the specifications for this product.


Please complete the pump sizing form to ensure the best pump option for your application
