Name: DAB K 40/100 M 1.8kW Centrifugal pump | DAB Centrifugal Pumps
Brand: DAB
SKU: P-DAB-K40-100-1.8KW
Price: 9819.0 ZAR
Availability: InStock

DAB K 40/100 M Double Impeller Centrifugal Pump 1.8kW

Store/AC Pumps/DAB/DAB Centrifugal Pumps

Product Details

Brand: DAB

Weight: 14.35 kg

DAB K 40/100 Centrifugal Pump

DAB twin-impeller centrifugal pump designed for the realization of pressurization units in water systems and filling of pressure vessels. Suitable for sprinkler systems and other general water supply uses. DAB centrifugal pumps are commonly used in residential and commercial buildings to provide a consistent supply of water for various purposes, such as drinking, showering, and washing. They are also used in agriculture for irrigation systems to distribute water to crops, ensuring proper hydration for plant growth.

Specifications

Operating range: from 1,2 to 30 m3/h with head up to 97 metres
Liquid temperature range: from -10°C to +50°C
Maximum ambient temperature: +40°C
Maximum operating pressure: 6 bar (600 kPa)

Constructional features of the pump

Cast iron pump body and motor support.
Techno-polymer impeller.
Carbon/ceramic mechanical seal.

Constructional features of the motor

Induction motor, closed and cooled with external ventilation.
Rotor mounted on over sized greased sealed-for-life ball bearings to ensure silent running and long life.

Liquid quality requirements

Clean, free from solids or abrasive substances, non viscous, non aggressive, non crystallized, chemically neutral, close to the characteristics of water.

Installation:

Fixed in a horizontal or vertical position, as long as the motor is above the pump.
