DAB K 45/50 M Double Impeller Centrifugal Pump 1.1kW
Product Details
Brand: DAB
Weight: 14.35 kg
DAB K 45/50 Centrifugal Pump
DAB twin-impeller centrifugal pump designed for the realization of pressurization units in water systems and filling of pressure vessels. Suitable for sprinkler systems and other general water supply uses. DAB centrifugal pumps are commonly used in residential and commercial buildings to provide a consistent supply of water for various purposes, such as drinking, showering, and washing. They are also used in agriculture for irrigation systems to distribute water to crops, ensuring proper hydration for plant growth.
Specifications
-
Operating range: from 1,2 to 30 m3/h with head up to 97 metres
- Liquid temperature range: from -10°C to +50°C
-
Maximum ambient temperature: +40°C
- Maximum operating pressure: 8 bar (800 kPa)
Constructional features of the pump
- Cast iron pump body and motor support.
- Techno-polymer impeller.
- Carbon/ceramic mechanical seal.
Constructional features of the motor
- Induction motor, closed and cooled with external ventilation.
- Rotor mounted on over sized greased sealed-for-life ball bearings to ensure silent running and long life.
Liquid quality requirements
Clean, free from solids or abrasive substances, non viscous, non aggressive, non crystallized, chemically neutral, close to the characteristics of water.
Installation:
Fixed in a horizontal or vertical position, as long as the motor is above the pump.
