DAH 550 Watt Solar Panel STD (Full Screen)

TECHNICAL DETAILS:

• Maximum system voltage 1500V DC
• Operating Temperature -40 ~ +85°C
• Maximum series fuse rating 20A
• Snow load, frontside 5400Pa
• Wind load, backside 2400Pa
• Nominal operating cell temperature 45°C±2°C
• Maximum Power (Pmax) 545
• Open-circuit Voltage (Voc) 74.5
• Maximum Power Voltage (Vmp) 62.8
• Short-circuit Current (Isc) 9.25
• Maximum Power Current (Imp) 8.68
• Module Efficiency (%) 21.09

Weight & Dimension

2279×1134×32mm

29kg

Warranty

12-year Material & technology warranty

25-year Linear power output warranty
