Growatt 5kW Inverter (High Voltage MPPT)
Product Details
Brand: 4SR Series Borehole Pump System
Sunsynk Solar Hybrid Inverters: 5kW Sunsynk Hybrid Inverter
Solar Batteries: Lithium-ion Solar Batteries
Weight: 12 kg
Growatt 5kW Solar Inverter (Off-Grid/UPS)
Growatt ES offers a high voltage MPPT input and can manage 5500W of PV array. An inverter that will power your appliances during the day/night and can be utilised as a UPS.
The Growatt SPF5000ES series inverter is one of the most comprehensive Off-Grid inverters offered by Growatt. This inverter is used for backup power, grid interactive or off-grid applications.
View applications Video
FEATURES:
- 220V single phase, pure sine wave inverter
- Self consumption & feed-in to the grid
- Auto re-start while AC is recovering
- Programmable supply priority for battery or grid
- Programmable multiple operation modes; on-grid / off-grid & UPS
- Configurable battery charging – current / voltage based on applications by LCD setting
- Configurable AC / solar / generator charger priority by LCD settinCompatible with mains voltage or generator power
- Overload / over-temperature / short-circuit protection
- Smart battery charger designer optimised battery protection
- Built-in MPPT Controller
- Available BMS (Battery Management System) Communication Port
- Works with or without battery
- Optional WIFI/GPRS remote monitoring
- Parallel up to 6 inverters
- Integrated UPS (uninterrupted power supply) function
SPECIFICATIONS:
- Max PV Power: 5500W
- Rated DC Power: 5000W
- Max DC Input Voltage: 450V
- MPPT Voltage Range: 120~430V
- MPPT Input Lines: 1
- Battery Type: Lead-Acid or Li-ion Battery
- Battery Rated Voltage: 48V
- Max Charge Current – 100A Solar / 80A on AC
- Max AC Power: 5000W
- Peak Power (Off-Grid): 1.5 Times Rated Power,10s
- AC Output Range: 230Vac
- Off-Grid Output: 180~280Vac
- Communication with BMS: RS485; CANBUS
- Installation Style: Wall-mounted
FINISHING:
Powder coated 2 tone – White + Black
DIMENTIONS (mm):
- Weight (kg): 12
- Size (Length x Width x Height): 135 x 330 x 485 mm
WARRANTY:
2 Years Manufacurers Warranty – Terms & Conditions apply.
